GDDR Memory Controller and PHY IP
Rambus GDDR6 controllers, PHYs and memory interface subsystems provide high-bandwidth, low-latency memory performance for AI/ML, graphics and HPC applications.
| Version | Maximum Data Rate (Gb/s) | Subsystem | Controller | PHY |
|---|---|---|---|---|
| GDDR6 | 24 |  Product Brief |
Product Brief |
Product Brief |
| GDDR6 | 16 | Product Brief |
Product Brief |
Product Brief |
GDDR Controller IP
| Feature | GDDR6 Controller |
|---|---|
| Speed Per Pin (Gb/s) | Up to 24 |
| Channels | 2 |
| Channel Width (bits) | 16 |
| Queue-Based Interface | Yes |
| Look-Ahead Command Processing | Yes |
| Clamshell Mode | x8 and x16 |
| Logic Interface | AXI or Native |
| Controller Interface | DFI Compatible |
| Add-On Cores | In-line ECC Multi-Port Front-End Reorder Read-Modify-Write Memory Test Memory Test Analyzer |
GDDR PHY IP
| Feature | 24G GDDR6 PHY | 16G GDDR6 PHY |
|---|---|---|
| Speed Bins (Gb/s) | 14-24 | 12-16 |
| Maximum Bandwidth (GB/s) | 96 | 64 |
| Channels | 2 | 2 |
| Channel Width (bits) | 16 | 16 |
| Controller Interface | DFI 3.1 Style | DFI 3.1 Style |
| PHY Independent Mode | Yes | Yes |
| Clamshell Mode | Yes | Yes |
| Selectable low-power operating states | Yes | Yes |
| Programmable driver/termination impedance | Yes | Yes |
| In-built test support | Yes | Yes |
| Metal stack | 15 layers | 13 layers |
| Bump pitch (um) | 110 | 130 |
| Integrated Reorder functionality | Yes | Yes |
| Register interface for state observation | Yes | Yes |
| LabStation™ software environment for system level bring-up, characterization, and validation | Yes | |
| Process Node | Contact Rambus | 7nm |
Complete GDDR6 Memory Subsystem Solution
Originally designed for graphics applications, GDDR is a high-performance memory solution that can be used in a variety of compute-intensive applications.
The Rambus GDDR6 controller fully supports the bandwidth and dual channel capabilities of the Rambus GDDR6 PHY. It maximizes memory bandwidth and minimizes latency via Look-Ahead command processing. The core is DFI compatible (with extensions for GDDR6) and supports AXI or native interface to user logic.
Originally designed for graphics applications, GDDR is a high-performance memory solution that can be used in a variety of compute-intensive applications.
The Rambus GDDR6 controller fully supports the bandwidth and dual channel capabilities of the Rambus GDDR6 PHY. It maximizes memory bandwidth and minimizes latency via Look-Ahead command processing. The core is DFI compatible (with extensions for GDDR6) and supports AXI or native interface to user logic.
From Data Center to End Device: AI/ML Inferencing with GDDR6
- Controller (source code)
- Testbench (source code)
- Complete documentation
PHY
Fully-characterized hard macro (GDSII)
- Gate-level and IO models
- Verilog behavior model
- Layout abstracts (.lef)
- Timing models (.lib)
- CDL netlists (.cdl)
- GDSII layout
- DRC & LVS reports
- Datasheet
- Package design guidelines
- ASIC/DFT manufacturing guidelines
- Test and characterization user guide
- Expert technical support
- Maintenance updates
- Customization
- SoC Integration
PHY
Comprehensive Chip and System Design Reviews
- Kickoff/Program Review
- Floor plan Review
- Test/Characterization Plan Review
- Package Design Review
- Board Design Review
- Final Chip Integration Review
- Bring-up and Test Review
Engineering Design Services:
- Package design
- System board layout
- Statistically-based signal and power integrity analysis
