In part one of this two-part blog series, Semiconductor Engineering editor in chief Ed Sperling spoke with Steven Woo, Rambus fellow and distinguished inventor, about the relationship between Moore’s Law and the thermal challenges faced by the semiconductor industry. Specifically, Woo highlighted how the breakdown of Dennard scaling around 2005 prompted GPU designers to place a major emphasis on thermal management and dissipation. In this blog post, we’ll take a closer look at thermal challenges and solutions across multiple verticals and applications including data centers, high performance computing (HPC), mobile devices and various memory types.

As Woo notes, power efficiency has become a top priority across the semiconductor industry in recent years.

“The amount of work that’s required [for thermal management] and the amount of space that’s required to actually deal with the heat is really growing over time – and is something that’s really unsustainable in our industry,” Woo states.

Commenting on battery-powered devices such as smartphones and tablets, Woo says that the mobile industry has developed multiple power-saving techniques like switching off specific system components that are not in use. These components can be quickly restarted when a change of operation is required.

“The ability to keep some silicon dark for certain amounts of time and to quickly turn it on while you turn off other parts of the silicon has been critical to managing the power and thermals for battery operated devices,” he adds.

Commenting on microfluidics, Woo observes that there is a lot of emphasis on using fluids to remove heat from certain systems.

“If you look at solutions like the latest version of the TPU from Google, there’s liquid cooling. If you look at supercomputing you see more and more machines at the high end that are using liquids to move the heat in a way that it can be dissipated more readily,” he explains. “In fact, there are inert liquids that you can even immerse whole boards into. Because they are inert, nothing shorts out. Having that direct liquid contact with something that is inert is by far the best way to remove the heat.”

Woo also emphasizes that DRAM is very sensitive to heat.

“If you are doing things correctly, then you [should be] designing [a system] so that the data movement doesn’t get affected [by the heat]. As a system designer, what you have to think about is how much power is going to be dissipated at the target data rate – and then think about everything you have to do to make sure the temperature remains relatively stable.”

As Woo points out, thermal challenges have prompted chip and memory architects to change the way systems are designed.

“For example, HBM memory uses stacking to try and reduce the distances that data has to move and reduce the amount of heat and power that needs to be dissipated. [The] graphics card [shown below] illustrates that even with those changes there’s still a lot of challenges with managing the thermals,” he elaborates.

“This is a modern graphics card that uses HBM memory and you can see once again it’s quite thick and quite big. As I remove the fan cover here what blows over the of the radiator structure we again see a really large really complicated kind of structure whose job it is to whisk the heat away from the processor.”

In this case, says Woo, the board itself (where the processing is done) is much smaller than what you see on a GDDR6 card.

“However, the thermal solution is just as beefy. So, you have the processor and two HBM RAMs on a very compact board. Again, most of the volume is really dedicated towards dealing with the thermals,” he continues.

“You can also see a copper plate whose job it is to whisk the heat away from the processor and the memory. As well, there is a heat pipe structure which moves that heat across a large set of bladed fins and air flows over those fins to dissipate the heat.”

According to Woo, engineers have formulated extensive design guidelines that detail how air should flow and where the heat should be moving to keep an entire system at a reasonable temperature.

“Over the years people have gone from relatively simple types of fan blade structures (like you can see in this card) to something that’s much more advanced,” he adds.

“There is also a big emphasis on efficiency of those fans, as well as having relatively large surface area of the blades, but also being quiet. The design and the angles and the way that the blades are shaped in heavily influences the ability to both move a lot of air and remain quiet.”

Written by Steven Woo for Rambus Press

In part 5 of this series, we discussed the most common memory systems that are used in the highest performance AI applications. These include on-chip memory, high bandwidth memory (HBM) and Graphics DDR SDRAM (GDDR SDRAM). In this blog post, we’ll take an in-depth look at on-chip memory, as well as explore some of the primary differences between HBM and GDDR6.

Suppose we set out to design a memory system that provides 256GB/s of memory bandwidth. The slide above illustrates the key differences when implementing such a memory system using HBM2 and GDDR6 DRAMs. As the table illustrates, data rates are one of the primary differences between the two memory types. Because there are fewer data wires, GDDR6 must transmit data at a higher data at a much higher data rate – 16 gigabits per second – as opposed to HBM2 which is running at two gigabits per second with many more wires. As such, the primary challenge associated with GDDR6 is signal integrity, although GDDR6 can enable a lower cost solution because it doesn’t involve intricate stacking like HBM2 does.

Now, let’s take a closer look at the PHY circuits which reside on the SoC and which connect the DRAMs to the SoC. With GDDR6, the amount of area that designers need to reserve on the SoC is between 1.5 and 1.75 times the area required for similar PHY circuits designed to communicate with HBM2 at the same total bandwidth of 256GB/s. In terms of power, it’s a more significant difference, as the GDDR6 PHYs consume anywhere between three-and-a-half to four-and-a-half times as much power as the PHY for an HBM2 implementation at the same bandwidth. From an engineering perspective, there is a definite SoC PHY area and power advantage for HBM2 memory systems.

But the area and power advantages of HBM2 PHYs comes at the expense of higher complexity and cost. This is because HBM2 requires an additional interposer, substrate and intricate stacking within the DRAM as well as between components in the system, all of which add extra cost and complexity, and which are currently exacerbated by the relative newness of the technology. Fundamentally, the decision to use HBM2 or GDDR6 comes down to how you trade off the most important design requirements against what matters most in your system. If you can handle the cost and complexity of an HBM2 implementation, then it is a very good solution. However, if your system requires either more standard manufacturing techniques, or can’t quite absorb the additional costs, then GDDR is a great solution.

On-chip Memory Benefits and Challenges

In the latter part of this blog post, we’ll be taking a closer look at the individual types of memories used in AI systems that I referenced earlier so we can walk through the benefits and challenges of each. On the slide above, we can see some of the benefits and challenges of on-chip memory. On-chip memory is used today in solutions such as Microsoft’s Brainwave, Graphcore’s IPU, and Cerebras’ Wafer-Scale Engine. As we’ve previously noted, one of the biggest benefits of on-chip memory is the extremely high bandwidth that it offers.

Today, on-chip memories can deliver on the order of tens of terabytes a second in the largest chips that are about the size of a reticle. On-chip memory also offers extremely low latency and very high-power efficiency, because the data doesn’t need to move very far. The low latency and high bandwidth enable high utilization of the compute engines, even when processing jobs with small batch sizes, which can be particularly important for cloud-based infrastructures.

In terms of challenges and disadvantages, on-chip memory has lower storage capacity compared to external DRAM, although systems designers are implementing some interesting techniques to extend the capacity. For example, instead of saving intermediate results during more complex calculations, results are simply recalculated because it’s cheaper and faster to perform computation than to store and retrieve data from on-chip and external memory. In addition to limited capacity, on-chip memory is challenged by scalability, especially when it comes to large AI models.

Multiple FPGAs at datacenter scale can form a persistent DNN HW microservice, enabling scale out of models at ultra-low latencies

On the bottom left of the slide above, the Brainwave approach to system scalability is illustrated by the chaining together of multiple FPGA cards to solve and implement some of their larger networks.

HBM Benefits and Challenges

Let’s take a closer look at HBM now. One of the primary benefits of HBM is that it achieves very high bandwidth, the highest bandwidth for any external memory device today, up to 256 gigabytes a second of bandwidth per HBM2 DRAM stack. HBM also offers very good power efficiency because it’s running many I/Os – 1,024 – at a relatively low data rate of two gigabits per second. There are a number of solutions, especially in the AI space, that are adopting HBM2, including nVidia’s Tesla V100 and the second-generation Google TPU.

HBM implementations are challenged by the high number of I/Os which requires a silicon interposer to place the large number of data wires in close proximity to each other. There’s additional cost and design complexity with all the stacking involved, both within the HBM DRAM stack, as well as stacking the components together on top of the interposer and the substrate before it goes onto the PCB. The system engineering challenges associated with this stacking, and the complexity with keeping the silicon cool to maintain reliability, all add to the difficulty of implementing HBM2 solutions. Still, if it’s something that you can tolerate in terms of the cost and the design complexity, HBM2 can be a great choice for external bandwidth solutions.

GDDR6 Benefits and Challenges

GDDR offers a good middle ground between performance, complexity and cost. So, you can get very high bandwidth and capacity because it is an external type of DRAM that’s already packaged. It’s also easier to integrate, while the system engineering is much simpler compared to a memory type like HBM. GDDR is a great solution for systems that are particularly cost-sensitive or when HBM can’t be easily implemented.

The primary challenge associated with GDDR is running at very high data rates. Although signal integrity becomes more difficult, GDDR is implementable at these speeds with well-designed and well-managed PHYs, packages and boards.

On the lower left of the slide above, you can see a screen capture and an eye diagram that illustrates some of the work Rambus did several years ago in preparation for achieving GDDR6 data rates. This work proved the ability to signal at these high data rates across standard PCBs and included technology development to enable SoC PHYs to achieve these speeds.
